LXS type coarse crusher 500

I. Main structure: It consists of motor, main shaft, bearing, bearing seat, rotating knife seat, rotary knife, power system, fixed knife seat, fixed knife, screen parts, hopper, body, circulating cooling water system and other components.

II. Main use: The coarse crusher is a kind of rubber crushing equipment which pulverizes non-metallic mass, block and flake (30-60mm) materials into 3-28mm particles and flakes at normal temperature (standard mesh screen) Φ13).

III. Working principle: The motor drives the spindle to rotate at a low speed and a medium speed, so that the rotating knife mounted on the rotating knife seat and the fixed knife mounted on the fixed knife seat are relatively sheared, torn and squeezed, when the tire recycling equipment When the material enters the pulverization chamber, the pulverizing knife group pulverizes the material by shearing, tearing and squeezing, so that the material meeting the fineness requirement is discharged through the sieve mesh, and the large particle size is pulverized by the cycle; the pulverizing body has a built-in circulation The cooling water is cooled to protect the tool and reduce the temperature of the crushing chamber.

IV, equipment structure characteristics

1 The double-layer structure feed hopper effectively absorbs the noise generated during the production process.

2. Built-in circulating water cooling system can effectively reduce the temperature of the tool and the crushing chamber during the working process.

3 Special alloy material tool, impact resistance, wear resistance, good toughness; toothed tool structure, lower cutting energy consumption, high efficiency and longer life.

4 Adopt active rotating grid structure for easy maintenance.

V, main technical parameters

VI, LXS500 type rubber fine crusher main technical parameters
